The Morin France inverted ventilation system, 215m3/h version, is a solution specifically designed for fire-rated safety cabinets. It ensures a positive airflow, creating overpressure within the cabinet to prevent odor mixing and cross-contamination of stored products. This system is particularly studied for the storage of explosive materials or narcotics, and is delivered with clamps and ducting. Air is drawn from outside to be injected into the cabinet evenly at all levels, thus guaranteeing non-contamination of products among themselves within the compartment. This model is tested and approved by professional clients and integrates with safety cabinets compliant with EN 14470-1 and FM 6050 standards.
Inverted Ventilation System Features
- Airflow : 215 m3/h (standard version)
- Operating Principle : Positive airflow, creates overpressure in the cabinet
- Application : Storage of explosive materials or narcotics
- Benefit : Prevents odor mixing and product non-contamination
- Delivered with : Clamps and ducting
- Other version available : PRO 300 m3/h
Key Features of the Associated Cabinet
- Fire Resistance : 30 minutes
- Compliance : EN 14470-1 and FM 6050 standards (world premiere)
- Sealing : Thermo-expanding seals
- Doors : Held in open position
- Automatic Closure : Thermoregulated at 50°C
- Dimensions : Several available in catalog and on request
- Stability : Jacking feet for leveling
- Locking : 3-point key lock
- Security : Anti-spark lock
- Available Versions : Low cabinet 1 or 2 doors, High cabinet 1 or 2 doors
Compliance of the Associated Cabinet
- EN 14470-1 (04/2004) and EN 1363-1 (06/2000) Standard : Tested and approved type 30 minutes
- FM 6050 Standard (Factory Mutual International) : Tested and approved 10 minutes
- Standardized Pictograms : Compliant with ISO 3864, NF X08.003, Directive 92/58/CEE, EN 14470-1 (04-2004) and FM specifications
Advantages of the Associated Cabinet
- Fire Resistance : 30 minutes according to ISO 834 standardized curve
- Movement : Base with cover for easy pallet truck movement (empty), except for "under-bench" models
- Automatic Closure : With predominance of leaves and doors held in open position thanks to thermal fuses triggering from 43°C (depending on model)
Passive Safety of the Associated Cabinet
- Construction : Insulating panels offering high resistance to chemical aggressions
- Frame : Light grey RAL 7035 with yellow RAL 1023 edged panels
- Signaling : By standardized symbols
- Shelves : Retention shelves adjustable in height at 32 mm increments
- Retention : Removable retention sump at the bottom
Active Safety of the Associated Cabinet
- Ventilation : Ø 100 mm orifices for possible connection
- Doors : With automatic closure with predominance of leaves
- Door Holding : System with automatic closure in case of fire
- Locking : 3-point key lock
- Lock : Anti-spark
- Leveling : Jacking feet for leveling
Technical Specifications of the Associated Cabinets
- Low Cabinet 1 door Version :
- External Dimensions : 635 x 605 x 630 mm
- Internal Dimensions : 365 x 45 x 420 mm
- Retention : 1 retention sump
- Maximum Load : 30 kg
- Low Cabinet 2 doors Version :
- External Dimensions : 635 x 1115 x 630 mm
- Internal Dimensions : 365 x 1050 x 420 mm
- Retention : 1 retention sump
- Maximum Load : 50 kg
- High Cabinet 1 door Version :
- External Dimensions : 1980 x 605 x 550 mm
- Internal Dimensions : 1580 x 495 x 420 mm
- Shelves : 3 shelves (admissible load 30 kg per shelf)
- Retention : 1 retention sump
- High Cabinet 2 doors Version :
- External Dimensions : 1980 x 1115 x 550 mm
- Internal Dimensions : 1580 x 1050 x 420 mm
- Shelves : 3 shelves (admissible load 50 kg per shelf)
- Retention : 1 retention sump
